JCB 81 Crawler Excavator Specifications

jcb

33,00,000 - ₹35,60,000

The JCB 81 Crawler Excavator is an 8-tonne machine designed for high efficiency in urban infrastructure projects, irrigation, rural developments, brickworks, ponds, and fisheries. Powered by a 57 kW engine, it offers excellent bucket and dipper tear-out forces, resulting in higher output and faster completion of work. With a remarkable 15% reduction in fuel consumption, it saves up to Rs 1 lac annually, making it an economical choice for contractors. The excavator also features a spacious, comfortable cabin with enhanced visibility, reducing operator fatigue. Maintenance is made easy with accessible check points, extended hydraulic oil life, and JCB's advanced LiveLink telematics system, providing real-time machine data and GPS tracking. This robust machine delivers outstanding performance with lower operational costs, making it ideal for diverse construction needs.

JCB 81 Crawler Excavator Specifications

ENGINE

Engine Power
76HP
Engine Brand
Kirloskar
Fuel Tank Capacity
164L
Rated Speed
2,200rpm
Engine Model
4R 1040 NA

EXCAVATOR PERFORMANCE

Max Digging Depth
4.08m
Max Dumping Height
5.40m
Max Reach at Ground
6.32m
Arm Crowd Force
4130kgf
Bucket Breakout Force
5760kgf
Bucket Capacity
0.32

DIMENSIONS

Ground Clearance
365mm
Overall Height
2.77m
Overall Length
6.23m
Overall Width
2.30m

HYDRAULIC SYSTEM

Hydraulic Flow Rate
140.6L/min
Hydraulic Pressure (Implement Circuit)
284kgf/cm²
Hydraulic Pressure (Swing Circuit)
225kgf/cm²
Hydraulic Pressure (Travel Circuit)
284kgf/cm²
