Tata Hitachi ZAXIS 870-5G Crawler Excavator
Trishul Tread Private Limited
The Tata Hitachi ZAXIS 870-5G Crawler Excavator excels in large-scale mining and construction with its powerful 483 HP engine and 82,300 kg operating weight. Designed for efficiency, it features the HIOS IIIB hydraulic system, offering swift front movements and a 9% boost in swing torque, while reducing fuel consumption by 4% and further in ECO mode. Its robust undercarriage and strengthened upper structure ensure durability and reliable performance in challenging environments. The excavator’s advanced cooling system, with a parallel arrangement of the radiator and oil cooler, enhances operational efficiency. Additionally, it provides ease of use with versatile attachments and simplified maintenance, making it an excellent choice for high productivity and cost-effective operation.
Tata Hitachi ZAXIS 870-5G Crawler Excavator
Trishul Tread Private Limited
The Tata Hitachi ZAXIS 870-5G Crawler Excavator excels in large-scale mining and construction with its powerful 483 HP engine and 82,300 kg operating weight. Designed for efficiency, it features the HIOS IIIB hydraulic system, offering swift front movements and a 9% boost in swing torque, while reducing fuel consumption by 4% and further in ECO mode. Its robust undercarriage and strengthened upper structure ensure durability and reliable performance in challenging environments. The excavator’s advanced cooling system, with a parallel arrangement of the radiator and oil cooler, enhances operational efficiency. Additionally, it provides ease of use with versatile attachments and simplified maintenance, making it an excellent choice for high productivity and cost-effective operation.
Product Description
The Tata Hitachi ZAXIS 870-5G Crawler Excavator excels in large-scale mining and construction with i...
View the full brochure
Tata Hitachi ZAXIS 870-5G Crawler Excavator Comparison with Similar Crawler Excavator

Tata Hitachi ZAXIS 870-5G Crawler Excavator
Engine Brand
Isuzu
Engine Model
BB-6WG1XQA-04
Engine Power
483HP
Max Torque
1945Nm
Rated Speed
1800rpm
Displacement
15.68L
Fuel Tank Capacity
1110L
Hydraulic Flow Rate
2 x 512L/min
Hydraulic Pressure (implement Circuit)
325kgf/cm²
Hydraulic Pressure (swing Circuit)
290kgf/cm²
Hydraulic Pressure (travel Circuit)
350kgf/cm²
Hydraulic Pressure (pilot Circuit)
40kgf/cm²
Operating Weight
80.8Ton
Ground Pressure (600mm Track)
1.23kgf/cm²
Max Digging Depth
9.5m
Max Reach At Ground
14.6m
Max Dumping Height
9.7m
Bucket Capacity
4.5m³
Bucket Breakout Force
-
Arm Crowd Force
28600kgf
Overall Length
14.8m
Overall Width
4.4m
Overall Height
4.7m
Ground Clearance
890mm

Zoomlion ZE375G Crawler Excavator
Engine Brand
CUMMINS
Engine Model
QSL
Engine Power
-
Max Torque
-
Rated Speed
-
Displacement
8.9 L
Fuel Tank Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
37.5Ton
Ground Pressure (600mm Track)
-
Max Digging Depth
7.075m
Max Reach At Ground
-
Max Dumping Height
7.075m
Bucket Capacity
1.9m³
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
11.23m
Overall Width
3.19m
Overall Height
3.78m
Ground Clearance
-

Zoomlion ZE960G Crawler Excavator
Engine Brand
SCANIA
Engine Model
DC16
Engine Power
-
Max Torque
-
Rated Speed
-
Displacement
16L
Fuel Tank Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
95Ton
Ground Pressure (600mm Track)
-
Max Digging Depth
0.725m
Max Reach At Ground
-
Max Dumping Height
7.815m
Bucket Capacity
7 m³m³
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
13.695m
Overall Width
4.44m
Overall Height
5.445m
Ground Clearance
-

XCMG XE80U Crawler Excavator
Engine Brand
Kubota
Engine Model
V3307CRTE5
Engine Power
-
Max Torque
9.31 Nm
Rated Speed
1500rpm
Displacement
3.3L
Fuel Tank Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
9.5Ton
Ground Pressure (600mm Track)
-
Max Digging Depth
-
Max Reach At Ground
-
Max Dumping Height
-
Bucket Capacity
0.35m³
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
-
Overall Width
-
Overall Height
-
Ground Clearance
-

Tata Hitachi EX 2600-7 Crawler Excavator
Engine Brand
Cummins
Engine Model
QSKTA50-CE (FCO, T4F/EU Stage V)
Engine Power
1500HP
Max Torque
-
Rated Speed
1800rpm
Displacement
50L
Fuel Tank Capacity
5300L
Hydraulic Flow Rate
4 x 375 L/min
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
257Ton
Ground Pressure (600mm Track)
1.91kgf/cm²
Max Digging Depth
8.2m
Max Reach At Ground
16m
Max Dumping Height
10.1m
Bucket Capacity
19.5m³
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
10.3m
Overall Width
8m
Overall Height
7.2m
Ground Clearance
770mm
