Tata Hitachi EX 70 Prime Mini Excavator
Trishul Tread Private Limited
₹3,500,000 - ₹3,600,000
The Tata Hitachi EX 70 Prime Series Construction Excavator combines power, efficiency, and comfort in a robust 7-ton machine. With a 49 PS engine and an operating weight of 7,200 kg, it excels in heavy-duty excavation and material handling. Its bucket capacity ranges from 0.13 to 0.68 m³, making it versatile for various tasks. The EX 70 Prime Series features advanced hydraulic systems and high fuel efficiency, ensuring superior performance and lower operating costs. It also offers enhanced operator comfort with ergonomic controls, an adjustable seat, and optional air conditioning. Built for durability with reinforced components and minimal maintenance requirements, this excavator is ideal for construction, infrastructure, and utility work, providing reliability, safety, and long-term value.
Tata Hitachi EX 70 Prime Mini Excavator
Trishul Tread Private Limited
₹3,500,000 - ₹3,600,000
The Tata Hitachi EX 70 Prime Series Construction Excavator combines power, efficiency, and comfort in a robust 7-ton machine. With a 49 PS engine and an operating weight of 7,200 kg, it excels in heavy-duty excavation and material handling. Its bucket capacity ranges from 0.13 to 0.68 m³, making it versatile for various tasks. The EX 70 Prime Series features advanced hydraulic systems and high fuel efficiency, ensuring superior performance and lower operating costs. It also offers enhanced operator comfort with ergonomic controls, an adjustable seat, and optional air conditioning. Built for durability with reinforced components and minimal maintenance requirements, this excavator is ideal for construction, infrastructure, and utility work, providing reliability, safety, and long-term value.
Product Description
The Tata Hitachi EX 70 Prime Series Construction Excavator combines power, efficiency, and comfort i...
View the full brochure
Tata Hitachi EX 70 Prime Mini Excavator Comparison with Similar Mini Excavators

Tata Hitachi EX 70 Prime Mini Excavator
Engine Brand
TATA
Engine Model
497 DI 38 BSIII
Engine Power
48.33HP
Max Torque
222Nm
Rated Speed
2000rpm
Displacement
-
Hydraulic Flow Rate
2×60L/min
Hydraulic Pressure (implement Circuit)
265kgf/cm²
Hydraulic Pressure (swing Circuit)
235kgf/cm²
Hydraulic Pressure (travel Circuit)
280kgf/cm²
Hydraulic Pressure (pilot Circuit)
35kgf/cm²
Operating Weight
7.2Ton
Max Digging Depth
4.6m
Max Reach At Ground
6.6m
Max Digging Height
-
Max Dumping Height
5.4m
Bucket Capacity
0.68m³
Bucket Breakout Force
-
Arm Crowd Force
3700kgf
Overall Length
6.3m
Overall Height
2.6m
Ground Clearance
360mm
Fuel Tank Capacity
135L

Kobelco SK80 Mini Excavator
Engine Brand
YANMAR
Engine Model
4TN98S
Engine Power
46.67HP
Max Torque
212Nm
Rated Speed
2100 rpm
Displacement
3.319 L
Hydraulic Flow Rate
126L/min
Hydraulic Pressure (implement Circuit)
300kgf/cm²
Hydraulic Pressure (swing Circuit)
250kgf/cm²
Hydraulic Pressure (travel Circuit)
300kgf/cm²
Hydraulic Pressure (pilot Circuit)
33kgf/cm²
Operating Weight
7.24 Ton
Max Digging Depth
-
Max Reach At Ground
-
Max Digging Height
-
Max Dumping Height
-
Bucket Capacity
0.35m³
Bucket Breakout Force
5375.69 kgf
Arm Crowd Force
4019.57 kgf
Overall Length
-
Overall Height
-
Ground Clearance
-
Fuel Tank Capacity
-

Hyundai R35Z-9 Mini Excavator
Engine Brand
Yanmar
Engine Model
3TNV88
Engine Power
-
Max Torque
106.8Nm
Rated Speed
-
Displacement
1.642L
Hydraulic Flow Rate
111.7L/min
Hydraulic Pressure (implement Circuit)
230kgf/cm²
Hydraulic Pressure (swing Circuit)
200kgf/cm²
Hydraulic Pressure (travel Circuit)
230kgf/cm²
Hydraulic Pressure (pilot Circuit)
30kgf/cm²
Operating Weight
3.75Ton
Max Digging Depth
3.15m
Max Reach At Ground
5.24m
Max Digging Height
-
Max Dumping Height
-
Bucket Capacity
-
Bucket Breakout Force
-
Arm Crowd Force
1990kgf
Overall Length
4.79m
Overall Height
-
Ground Clearance
290mm
Fuel Tank Capacity
42L
CAT 301.7 CR Mini Excavator
Engine Brand
-
Engine Model
C1.1
Engine Power
21HP
Max Torque
-
Rated Speed
-
Displacement
1.13L
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
1.91Ton
Max Digging Depth
2.54m
Max Reach At Ground
4.05m
Max Digging Height
3.48m
Max Dumping Height
-
Bucket Capacity
-
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
-
Overall Height
-
Ground Clearance
-
Fuel Tank Capacity
-

Hyundai HX35AZ Mini Excavator
Engine Brand
Kubota
Engine Model
D 1703
Engine Power
-
Max Torque
97Nm
Rated Speed
1320 rpm
Displacement
-
Hydraulic Flow Rate
2 x 37.4 + 23.1L/min
Hydraulic Pressure (implement Circuit)
230kgf/cm²
Hydraulic Pressure (swing Circuit)
210kgf/cm²
Hydraulic Pressure (travel Circuit)
230kgf/cm²
Hydraulic Pressure (pilot Circuit)
40kgf/cm²
Operating Weight
4.13Ton
Max Digging Depth
3.28m
Max Reach At Ground
5.46m
Max Digging Height
5.02m
Max Dumping Height
3.61m
Bucket Capacity
0.11m³
Bucket Breakout Force
-
Arm Crowd Force
1623kgf
Overall Length
4.7m
Overall Height
-
Ground Clearance
383mm
Fuel Tank Capacity
46.8L
