SDLG G9138H Motor Grader
West India Equipments Pvt Ltd
Gujarat
The SDLG G9138H Motor Grader is a powerful and reliable machine designed to deliver exceptional performance in a wide range of grading applications. With a gross power of 148hp at 2200rpm, it ensures smooth and efficient operation even under demanding conditions. Weighing 13,000 kg, this CEV-IV certified grader is built for heavy-duty tasks and long-lasting durability. The 3658 mm blade length offers high precision in road leveling, base layer preparation, and surface finishing. Whether it's for highway construction, mining road maintenance, or municipal snow removal, the G9138H ensures optimal grading accuracy and fuel efficiency. Its advanced hydraulic system and robust structure make it a trusted choice for contractors seeking dependable performance and reduced operating costs. Choose SDLG G9138H for consistent grading results, every time.
SDLG G9138H Motor Grader
West India Equipments Pvt Ltd
Gujarat
The SDLG G9138H Motor Grader is a powerful and reliable machine designed to deliver exceptional performance in a wide range of grading applications. With a gross power of 148hp at 2200rpm, it ensures smooth and efficient operation even under demanding conditions. Weighing 13,000 kg, this CEV-IV certified grader is built for heavy-duty tasks and long-lasting durability. The 3658 mm blade length offers high precision in road leveling, base layer preparation, and surface finishing. Whether it's for highway construction, mining road maintenance, or municipal snow removal, the G9138H ensures optimal grading accuracy and fuel efficiency. Its advanced hydraulic system and robust structure make it a trusted choice for contractors seeking dependable performance and reduced operating costs. Choose SDLG G9138H for consistent grading results, every time.
Product Description
The SDLG G9138H Motor Grader is a powerful and reliable machine designed to deliver exceptional perf...
View the full brochure
SDLG G9138H Motor Grader Comparison with Similar Motor Grader
SDLG G9138H Motor Grader
Engine Brand
-
Engine Model
WP4.6NG150E501
Engine Power
148HP
Max Torque
640Nm
Rated Speed
2200rpm
Displacement
4.58L
Fuel Tank Capacity
-
Transmission Type
Counter shaft power shift Auto manual
Number Of Gears (fwd/rev)
6F / 3R
Max Travel Speed
39km/h
Service Brake Type
MICO single-circuit, hydraulically operated
Parking Brake Type
Mechanical control on transmission
Steering Type
Load-sensing and hydraulic steering
Steering Angle
50°
Oscillation Angle
160°
Turning Radius
6.5m
Operating Weight
13.0Ton
Front Axle Load
3700kg
Rear Axle Load
9300kg
Hydraulic Flow Rate
25L/min
Hydraulic Pressure
180Bar
Overall Length
8.12m
Overall Width
2.41m
Overall Height
3.235m
Ground Clearance
0.59mm
Blade Length
3.658m
Blade Height
0.58m
Max Lift Above Ground
0.38m
Max Depth Of Cut
0.575m
Blade Tilt Angle
90°
Blade Pitch Angle
-
Blade Rotation Angle
-
Liugong CLG 414 BSIII Motor Grader
Engine Brand
CUMMINS INDIA
Engine Model
6BTAA5.9
Engine Power
150HP
Max Torque
655Nm
Rated Speed
2200rpm
Displacement
-
Fuel Tank Capacity
250L
Transmission Type
Power Shift
Number Of Gears (fwd/rev)
6F/3R
Max Travel Speed
41km/h
Service Brake Type
Shoe
Parking Brake Type
Shoe
Steering Type
Full hydraulic steering
Steering Angle
90°
Oscillation Angle
30°
Turning Radius
7.2m
Operating Weight
14.3Ton
Front Axle Load
-
Rear Axle Load
-
Hydraulic Flow Rate
-
Hydraulic Pressure
180Bar
Overall Length
9.21m
Overall Width
3.4m
Overall Height
3.66m
Ground Clearance
575mm
Blade Length
3.66m
Blade Height
0.61m
Max Lift Above Ground
0.485m
Max Depth Of Cut
0.575m
Blade Tilt Angle
70°
Blade Pitch Angle
-
Blade Rotation Angle
90°
Sany STG210C-10 Motor Grader
Engine Brand
Cummins
Engine Model
QSB6.7
Engine Power
225HP
Max Torque
1000Nm
Rated Speed
2200rpm
Displacement
6.7L
Fuel Tank Capacity
350L
Transmission Type
-
Number Of Gears (fwd/rev)
6 forward and 3 reverse
Max Travel Speed
42km/h
Service Brake Type
-
Parking Brake Type
-
Steering Type
-
Steering Angle
45°
Oscillation Angle
16°
Turning Radius
7.3m
Operating Weight
15.35Ton
Front Axle Load
-
Rear Axle Load
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Overall Length
11.1m
Overall Width
2.74m
Overall Height
3.31m
Ground Clearance
410mm
Blade Length
3.66m
Blade Height
0.62m
Max Lift Above Ground
0.48m
Max Depth Of Cut
0.63m
Blade Tilt Angle
9°
Blade Pitch Angle
25~75°
Blade Rotation Angle
360°
FINE 585HD Motor Grader
Engine Brand
Ashok Leyland
Engine Model
-
Engine Power
130HP
Max Torque
480Nm
Rated Speed
2200rpm
Displacement
3.84L
Fuel Tank Capacity
140L
Transmission Type
Power - Shift Transmission (AVTECH)
Number Of Gears (fwd/rev)
2 Forward / 2 Reverse
Max Travel Speed
20km/h
Service Brake Type
Foot pedal operated hydraulic brake through master cylinder
Parking Brake Type
Spring Applied Hydraulic Release (SAHR)
Steering Type
Hydraulic Power Steering
Steering Angle
45°
Oscillation Angle
20°
Turning Radius
10.26m
Operating Weight
9.495Ton
Front Axle Load
2710kg
Rear Axle Load
6750kg
Hydraulic Flow Rate
118L/min
Hydraulic Pressure
220Bar
Overall Length
-
Overall Width
-
Overall Height
-
Ground Clearance
-
Blade Length
3.05m
Blade Height
0.494m
Max Lift Above Ground
0.46m
Max Depth Of Cut
-
Blade Tilt Angle
40° Forward / 5° Backward°
Blade Pitch Angle
-
Blade Rotation Angle
360°
CASE 865C VHP Motor Grader
Engine Brand
FPT
Engine Model
F4HE613B*W002
Engine Power
220HP
Max Torque
930Nm
Rated Speed
2200rpm
Displacement
6.7L
Fuel Tank Capacity
380L
Transmission Type
-
Number Of Gears (fwd/rev)
-
Max Travel Speed
-
Service Brake Type
Disc, bathed in oil
Parking Brake Type
-
Steering Type
Hydrostatic power steering
Steering Angle
25°
Oscillation Angle
20°
Turning Radius
-
Operating Weight
-
Front Axle Load
-
Rear Axle Load
-
Hydraulic Flow Rate
186L/min
Hydraulic Pressure
175Bar
Overall Length
-
Overall Width
-
Overall Height
-
Ground Clearance
0.58 (front) mm
Blade Length
3.962m
Blade Height
0.622 m
Max Lift Above Ground
0.4445m
Max Depth Of Cut
0.7112m
Blade Tilt Angle
-
Blade Pitch Angle
87°
Blade Rotation Angle
360 °
