SANY SPT26 Telescopic Boom Lift

The SANY SPT26 Telescopic Boom Lift is engineered for high-reach efficiency, offering a maximum platform height of 26.7 meters and a working height of 28.7 meters—ideal for large construction and maintenance tasks. Its 20.3-meter horizontal outreach allows operators to access difficult-to-reach areas with ease. Equipped with a spacious 2.44m × 0.91m platform and a lifting capacity of up to 480kg, it supports multiple workers and tools simultaneously. The machine features 360° continuous turntable rotation, 180° platform rotation, and ±70° jib articulation for enhanced flexibility. With a 4WD×2WS drive system, 45% gradeability, and compact stowed dimensions, it performs seamlessly on uneven terrain and tight job sites. Powered by a reliable DEUTZ/KUBOTA engine, the SPT26 is the go-to solution for height-focused industrial operations.

Product Description

The SANY SPT26 Telescopic Boom Lift is engineered for high-reach efficiency, offering a maximum plat...

View the full brochure

SANY SPT26 Telescopic Boom Lift Comparison with Similar Telescopic Boom Lift

SANY SPT26 Telescopic Boom Lift

SANY SPT26 Telescopic Boom Lift

Get Latest Price
Rating
4.4

Engine Brand

DEUTZ / KUBOTA

Engine Model

TD2.9 / V3307-TE5B

Engine Power

74.29HP

Fuel Tank Capacity

2600L

Battery Voltage/cap.

160

Transmission Type

-

Drive Type

4WD

Max Travel Speed

6.0km/h

Travel Speed (raised)

0.8km/h

Gradeability

45%

Service Brake Type

-

Parking Brake Type

-

Steering Type

2WS

Turning Radius (inside)

3.66m

Turning Radius (outside)

6.86m

Operating Weight

15.7Ton

Max Lifting Capacity (unrestricted)

300kg

Max Lifting Capacity (restricted)

400kg

Hydraulic Oil Capacity

-

Hydraulic Flow Rate

-

Hydraulic Pressure

-

Overall Length

12.3m

Overall Width

2.49m

Overall Height

3.05m

Ground Clearance

0.41m

Wheelbase

3.05m

Turntable Tail Swing

1.5m

Max Platform Height

26.7m

Max Working Height

28.7m

Max Horizontal Outreach

20.3m

Platform Rotation

180°

Turntable Rotation

360 Continuous°

Jib Articulation

+70° / -65°°

Platform Size (l×w)

2.44×0.91m

Max Platform Occupants

3Persons

Tilt Alarm / Sensor

X-5° / Y-5°

Platform Entry Type

-

Tyres

-

Power Steering

-

Drive Enable / Alarms

-

Currently Viewing
SANY SPT22 Telescopic Boom Lift

SANY SPT22 Telescopic Boom Lift

Get Latest Price
Rating
4.4

Engine Brand

DEUTZ / KUBOTA

Engine Model

D2.9 / V2607-DI-T

Engine Power

48.8 / 49.0 HP

Fuel Tank Capacity

160L

Battery Voltage/cap.

-

Transmission Type

-

Drive Type

4WD

Max Travel Speed

5.5km/h

Travel Speed (raised)

1.1km/h

Gradeability

45 %

Service Brake Type

-

Parking Brake Type

-

Steering Type

2WS

Turning Radius (inside)

2.40m

Turning Radius (outside)

5.50m

Operating Weight

12.7Ton

Max Lifting Capacity (unrestricted)

300kg

Max Lifting Capacity (restricted)

480kg

Hydraulic Oil Capacity

-

Hydraulic Flow Rate

-

Hydraulic Pressure

-

Overall Length

11.0 m

Overall Width

2.45m

Overall Height

2.70m

Ground Clearance

0.31m

Wheelbase

2.50m

Turntable Tail Swing

1.50m

Max Platform Height

22.4m

Max Working Height

24.4m

Max Horizontal Outreach

16.5m

Platform Rotation

180°

Turntable Rotation

360 (Continuous) °

Jib Articulation

+70 / -65 °

Platform Size (l×w)

2.44 × 0.91 m

Max Platform Occupants

3Persons

Tilt Alarm / Sensor

X-5° / Y-5°

Platform Entry Type

-

Tyres

-

Power Steering

-

Drive Enable / Alarms

-
