Liugong 924E XD Crawler Excavator

LiuGong India Pvt Ltd

Haryana

The Liugong 924E XD Crawler Excavator is designed to tackle a wide range of demanding applications with its 23,600 kg operating weight and 166 HP engine. Equipped with a versatile bucket capacity of 1.25 m³ for general purpose and 1.15 m³ for heavy-duty tasks, it is ideal for medium to large earthmoving projects, delivering reliable performance in construction and excavation work. This excavator is perfect for quarrying and mining operations, where strength and stability are essential for handling heavy loads. Its robust design and powerful digging force make it well-suited for demolition projects, breaking down structures with efficiency and precision. Additionally, the Liugong 924E XD excels in road construction and maintenance, providing effective grading, material handling, and site preparation, ensuring maximum productivity on every job site.

Operating Weight
23.6Ton

Product Description

The Liugong 924E XD Crawler Excavator is designed to tackle a wide range of demanding applications w...

View the full brochure

Liugong 924E XD Crawler Excavator Comparison with Similar Crawler Excavator

Liugong 924E XD Crawler Excavator

Liugong 924E XD Crawler Excavator

Get Latest Price
Rating
4.4

Engine Brand

CUMMINS

Engine Model

QSB7

Engine Power

166 HP

Max Torque

658Nm

Hydraulic Pressure (implement Circuit)

380.4kgf/cm²

Hydraulic Pressure (swing Circuit)

290.6kgf/cm²

Hydraulic Pressure (travel Circuit)

349.8kgf/cm²

Hydraulic Pressure (pilot Circuit)

39.8kgf/cm²

Operating Weight

23.6Ton

Ground Pressure (600mm Track)

0.461kgf/cm²

Max Digging Depth

6.1m

Max Reach At Ground

9.136m

Max Dumping Height

6.832m

Bucket Capacity

1.35

Bucket Breakout Force

16213.5kgf

Arm Crowd Force

12746.5kgf

Overall Length

-

Overall Width

-

Overall Height

-

Ground Clearance

-

Rated Speed

2050rpm

Displacement

6.7L

Fuel Tank Capacity

420L

Hydraulic Flow Rate

487L/min

Currently Viewing
Zoomlion ZE385G Pro Crawler Excavator

Zoomlion ZE385G Pro Crawler Excavator

Get Latest Price
Rating
4.4

Engine Brand

CUMMINS

Engine Model

QSL

Engine Power

-

Max Torque

-

Hydraulic Pressure (implement Circuit)

-

Hydraulic Pressure (swing Circuit)

-

Hydraulic Pressure (travel Circuit)

-

Hydraulic Pressure (pilot Circuit)

-

Operating Weight

38Ton

Ground Pressure (600mm Track)

-

Max Digging Depth

7.075m

Max Reach At Ground

-

Max Dumping Height

6.885m

Bucket Capacity

2.0

Bucket Breakout Force

-

Arm Crowd Force

-

Overall Length

11.23m

Overall Width

3.19m

Overall Height

3.78m

Ground Clearance

-

Rated Speed

-

Displacement

8.9L

Fuel Tank Capacity

-

Hydraulic Flow Rate

-

XCMG XE155U Crawler Excavator

XCMG XE155U Crawler Excavator

Get Latest Price
Rating
4.4

Engine Brand

XCMG

Engine Model

Cummins B4.5

Engine Power

-

Max Torque

501.8Nm

Hydraulic Pressure (implement Circuit)

-

Hydraulic Pressure (swing Circuit)

-

Hydraulic Pressure (travel Circuit)

-

Hydraulic Pressure (pilot Circuit)

-

Operating Weight

17.5Ton

Ground Pressure (600mm Track)

-

Max Digging Depth

6.01m

Max Reach At Ground

-

Max Dumping Height

-

Bucket Capacity

0.64

Bucket Breakout Force

-

Arm Crowd Force

-

Overall Length

78.3m

Overall Width

26.8m

Overall Height

-

Ground Clearance

367.1mm

Rated Speed

-

Displacement

4.54L

Fuel Tank Capacity

249.8L

Hydraulic Flow Rate

-

Liugong 965E HD Crawler Excavator

Liugong 965E HD Crawler Excavator

Get Latest Price
Rating
4.4

Engine Brand

SCANIA

Engine Model

DC13 076A

Engine Power

444HP

Max Torque

2007Nm

Hydraulic Pressure (implement Circuit)

379.3kgf/cm²

Hydraulic Pressure (swing Circuit)

397.7kgf/cm²

Hydraulic Pressure (travel Circuit)

326.3kgf/cm²

Hydraulic Pressure (pilot Circuit)

-

Operating Weight

62.6Ton

Ground Pressure (600mm Track)

-

Max Digging Depth

6.83m

Max Reach At Ground

10.78m

Max Dumping Height

6.84m

Bucket Capacity

4.1

Bucket Breakout Force

35180.2kgf

Arm Crowd Force

30591.5kgf

Overall Length

11.87m

Overall Width

3.9m

Overall Height

3.05m

Ground Clearance

786mm

Rated Speed

2100rpm

Displacement

12.7L

Fuel Tank Capacity

880L

Hydraulic Flow Rate

896L/min

Sany SY210 SPARC + Crawler Excavator

Sany SY210 SPARC + Crawler Excavator

Get Latest Price
Rating
4.4

Engine Brand

-

Engine Model

-

Engine Power

-

Max Torque

-

Hydraulic Pressure (implement Circuit)

-

Hydraulic Pressure (swing Circuit)

-

Hydraulic Pressure (travel Circuit)

-

Hydraulic Pressure (pilot Circuit)

-

Operating Weight

-

Ground Pressure (600mm Track)

-

Max Digging Depth

-

Max Reach At Ground

-

Max Dumping Height

-

Bucket Capacity

-

Bucket Breakout Force

-

Arm Crowd Force

-

Overall Length

-

Overall Width

-

Overall Height

-

Ground Clearance

-

Rated Speed

-

Displacement

-

Fuel Tank Capacity

-

Hydraulic Flow Rate

-

Compare Crawler Excavator

Liugong 924E XD Crawler Excavator

Liugong 924E XD Crawler Excavator

Zoomlion ZE385G Pro Crawler Excavator

Zoomlion ZE385G Pro Crawler Excavator

Add any equipment
to compare

Product

Get instant quotation on whatsapp

Connect with "LiuGong India Pvt Ltd"

Connect with Seller Instantly

About Company

Company Name

LiuGong India Pvt Ltd

GST Number

07AABCL3456H2ZJ

Since

January 2002

Address

101, Okhla Industrial Estate Phase 3 Rd, Okhla Phase III, Okhla Industrial Estate, New Delhi, Delhi 110020 Phone: 011 2727 2200

LiuGong, officially Guangxi LiuGong Machinery Co., Ltd., is a leading Chinese construction machinery manufacturer headquartered in Liuzhou, China. Founded in 1958, LiuGong is one of the top global construction equipment companies and the largest manufacturer of wheel loaders worldwide. Its extensive product range includes wheel loaders, bulldozers, skid steer loaders, forklifts, motor graders, excavators, rollers, cranes, pavers, and more, serving diverse needs across construction, mining, and infrastructure sectors. Listed on the Shenzhen Stock Exchange, LiuGong continues to innovate and expand its reach, providing durable and reliable equipment solutions in over 100 countries.
