LiuGong 6210E Tandem Roller
LiuGong India Pvt Ltd
Delhi
The LiuGong 6210E Tandem Roller is powered by a Kirloskar 4R1190NA1 engine, delivering 74.5 hp @ 2200 rpm and peak torque of 300 N·m @ 1320 rpm with a displacement of 4.76 L. It uses a hydrostatic transmission and operates with a travel speed of 0–13 km/hr and working speed of 0–7 km/hr. Gradeability stands at 35% without vibration and 40% with vibration. The machine weighs 10,000 kg with front and rear drum loads of 5200 kg and 4800 kg respectively. It offers dual frequency settings of 42/50 Hz and amplitude settings of 0.4/0.8 mm. Drum width is 1750 mm, and it includes a 220 L fuel tank, 800 L water tank, and 90 L hydraulic oil tank. Features include a suspension seat, tool box, and optional GPS.
LiuGong 6210E Tandem Roller
LiuGong India Pvt Ltd
Delhi
The LiuGong 6210E Tandem Roller is powered by a Kirloskar 4R1190NA1 engine, delivering 74.5 hp @ 2200 rpm and peak torque of 300 N·m @ 1320 rpm with a displacement of 4.76 L. It uses a hydrostatic transmission and operates with a travel speed of 0–13 km/hr and working speed of 0–7 km/hr. Gradeability stands at 35% without vibration and 40% with vibration. The machine weighs 10,000 kg with front and rear drum loads of 5200 kg and 4800 kg respectively. It offers dual frequency settings of 42/50 Hz and amplitude settings of 0.4/0.8 mm. Drum width is 1750 mm, and it includes a 220 L fuel tank, 800 L water tank, and 90 L hydraulic oil tank. Features include a suspension seat, tool box, and optional GPS.
Product Description
The LiuGong 6210E Tandem Roller is powered by a Kirloskar 4R1190NA1 engine, delivering 74.5 hp @ 220...
View the full brochure
LiuGong 6210E Tandem Roller Comparison with Similar Tandem Roller
LiuGong 6210E Tandem Roller
Engine Brand
Kirloskar
Engine Model
4R1190NA1
Engine Power
74.5HP
Max Torque
300Nm
Rated Speed
2200rpm
Fuel Tank Capacity
220L
Displacement
4.76L
Transmission Type
Hydrostatic
Max Travel Speed
13km/h
Max Working Speed
7km/h
Gradeability Without Vibration
35%
Gradeability With Vibration
40%
Service Brake Type
Hydrostatic
Parking Brake Type
Mechanical Apply, Hydraulic Release
Steering Type
Hydrostatic
Steering Angle
35°
Oscillation Angle
-
Turning Radius
-
Operating Weight
10.0Ton
Front Axle Load
5200kg
Rear Axle Load
4800kg
Hydraulic Tank Capacity
90L
Frequency High
50Hz
Frequency Low
42Hz
Amplitude High
0.8mm
Amplitude Low
0.4mm
Overall Length
4.985m
Overall Width
1.925m
Overall Height
3.2m
Ground Clearance
270mm
Drum Width
1.75m
Water Tank Capacity
800L
Volvo DD90C Tandem Roller
Engine Brand
VECV
Engine Model
EE483TCI StageIV CEV
Engine Power
73.8 HP
Max Torque
-
Rated Speed
2200rpm
Fuel Tank Capacity
180 L
Displacement
-
Transmission Type
Closed-loop hydrostatic, parallel circuit to both drums
Max Travel Speed
12km/h
Max Working Speed
7 km/h
Gradeability Without Vibration
30%
Gradeability With Vibration
-
Service Brake Type
Dynamic hydrostatic through propulsion system
Parking Brake Type
SAHR on both drum drives
Steering Type
Articulated frame, center pivot steering
Steering Angle
30°
Oscillation Angle
10°
Turning Radius
7.285 m
Operating Weight
8.7Ton
Front Axle Load
4.22kg
Rear Axle Load
4.48kg
Hydraulic Tank Capacity
80L
Frequency High
50 Hz
Frequency Low
36 Hz
Amplitude High
1.0 mm
Amplitude Low
0.36mm
Overall Length
4.970 m
Overall Width
1.835 m
Overall Height
3.050m
Ground Clearance
305mm
Drum Width
1.676m
Water Tank Capacity
700L
Volvo DD100 Tandem Roller
Engine Brand
Cummins
Engine Model
QSB 4.5
Engine Power
129.9HP
Max Torque
-
Rated Speed
-
Fuel Tank Capacity
189L
Displacement
-
Transmission Type
Closed-loop hydrostatic, parallel circuit to both drums
Max Travel Speed
11.4 km/h
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
24.5%
Service Brake Type
Dynamic hydrostatic through propulsion system
Parking Brake Type
SAHR on front and rear drum drive motors
Steering Type
Center pivot (Articulated) steering
Steering Angle
40°
Oscillation Angle
10°
Turning Radius
3.558m
Operating Weight
10.025 Ton
Front Axle Load
5,200kg
Rear Axle Load
4,825kg
Hydraulic Tank Capacity
133 L
Frequency High
41.7Hz
Frequency Low
30.8 Hz
Amplitude High
1.01mm
Amplitude Low
0.41mm
Overall Length
5.086 m
Overall Width
2.845m
Overall Height
2.845m
Ground Clearance
0.430 mm
Drum Width
1.676m
Water Tank Capacity
984L
Hamm HC 119iD Tandem Roller
Engine Brand
ASHOK LEYLAND
Engine Model
H4C510122
Engine Power
99.2HP
Max Torque
-
Rated Speed
2200rpm
Fuel Tank Capacity
270L
Displacement
-
Transmission Type
-
Max Travel Speed
12.0km/h
Max Working Speed
7.0km/h
Gradeability Without Vibration
53%
Gradeability With Vibration
48%
Service Brake Type
-
Parking Brake Type
-
Steering Type
Articulated steering
Steering Angle
33°
Oscillation Angle
10°
Turning Radius
4.260m
Operating Weight
11.18Ton
Front Axle Load
6220kg
Rear Axle Load
4960kg
Hydraulic Tank Capacity
-
Frequency High
35Hz
Frequency Low
30Hz
Amplitude High
1.93mm
Amplitude Low
0.85mm
Overall Length
5.989m
Overall Width
2.280m
Overall Height
3.067m
Ground Clearance
470mm
Drum Width
2.140m
Water Tank Capacity
-
CASE 952 EX Tandem Roller
Engine Brand
Ashok Leyland
Engine Model
H4C4E7422
Engine Power
73.0HP
Max Torque
54.4Nm
Rated Speed
340rpm
Fuel Tank Capacity
140L
Displacement
3.83L
Transmission Type
-
Max Travel Speed
11.5km/h
Max Working Speed
5.5km/h
Gradeability Without Vibration
-
Gradeability With Vibration
36%
Service Brake Type
Hydrostatic
Parking Brake Type
SAHR (Spring Applied Hydraulically Released)
Steering Type
-
Steering Angle
-
Oscillation Angle
± 10˚°
Turning Radius
5.1m
Operating Weight
9050Ton
Front Axle Load
4410kg
Rear Axle Load
4640kg
Hydraulic Tank Capacity
70L
Frequency High
50Hz
Frequency Low
33Hz
Amplitude High
1.0mm
Amplitude Low
0.2mm
Overall Length
4.130m
Overall Width
1.905m
Overall Height
3.100m
Ground Clearance
244mm
Drum Width
-
Water Tank Capacity
-
