JLG 1250AJP Boom Lift Specifications

jlg

The JLG 1250AJP Boom Lift is a high-performance aerial platform designed for demanding tasks at extreme heights. With a working height of 40.30 meters and a horizontal outreach of 19.90 meters, it provides excellent access to hard-to-reach areas. Its 130-degree jib articulation and 360-degree continuous swing allow precise positioning for various applications, from skyscraper construction to bridge repairs. The lift's powerful diesel engine and 45% 4WD gradeability ensure reliable performance on rugged terrains. Its platform can support up to 450 kg for heavy-duty tasks, while the 18.44-meter up-and-over height enables smooth access to complex work areas. Whether for telecommunication tower maintenance, industrial facility upgrades, or facade cleaning, the JLG 1250AJP offers unparalleled versatility, durability, and safety, making it an ideal choice for challenging job sites.

JLG 1250AJP Boom Lift Specifications

ENGINE

Engine Brand
Deutz
Engine Model
TCD2.9L4 Tier 4
Engine Power
55.4kW
Fuel Tank Capacity
170L
Hydraulic Oil Capacity
201L

TRANSMISSION & PERFORMANCE

Gradeability
45%
Max Travel Speed (F)
5.2km/h

DIMENSIONS

Ground Clearance
300 (axle), 650 (chassis)mm
Overall Height
3.02m
Overall Length
14.48m
Overall Width
2.49 (retracted) – 3.81 (extended)m

PERFORMANCE

Horizontal Outreach
19.25m
Platform Height
38.3m
Platform Rotation
180°
Up and Over Clearance
18.44m

HYDRAULIC SYSTEM

Hydraulic Pressure
6.89Bar

OPERATING WEIGHT & LOAD CAPACITY

Max Platform Capacity
454 (restricted) / 227 (unrestricted)kg
Operating Weight
19958kg

STEERING & TURNING

Steering Type
2WS / 4WS
Turning Radius
2.44 – 4.39m
