JCB 135 Skid Steer Loader
JCB India Limited
Haryana
The JCB 135 Skid Steer Loader is a compact yet powerful machine designed for tough construction and material handling tasks. With a maximum operating capacity of 612 kg and a bucket capacity of 0.36 cu.m, it efficiently handles loading, unloading, and material moving in tight spaces. The 2.26 m dump height allows for convenient material disposal at elevated points, improving productivity on the job site. Its 1.52 m shovel width ensures precise control, making it ideal for clearing, grading, and leveling tasks. Powered by a robust 42 kW engine, the JCB 135 delivers exceptional performance, providing reliability and efficiency even in challenging conditions. This skid steer loader offers the perfect balance of power, capacity, and maneuverability, making it a valuable asset for a wide range of applications.
JCB 135 Skid Steer Loader
JCB India Limited
Haryana
The JCB 135 Skid Steer Loader is a compact yet powerful machine designed for tough construction and material handling tasks. With a maximum operating capacity of 612 kg and a bucket capacity of 0.36 cu.m, it efficiently handles loading, unloading, and material moving in tight spaces. The 2.26 m dump height allows for convenient material disposal at elevated points, improving productivity on the job site. Its 1.52 m shovel width ensures precise control, making it ideal for clearing, grading, and leveling tasks. Powered by a robust 42 kW engine, the JCB 135 delivers exceptional performance, providing reliability and efficiency even in challenging conditions. This skid steer loader offers the perfect balance of power, capacity, and maneuverability, making it a valuable asset for a wide range of applications.
Product Description
The JCB 135 Skid Steer Loader is a compact yet powerful machine designed for tough construction and ...
View the full brochure
JCB 135 Skid Steer Loader Comparison with Similar Skid Steer Loader

JCB 135 Skid Steer Loader
Hydraulic Flow Rate
125L/min
Hydraulic Pressure
230Bar
Hydraulic System Capacity
55L
Max Dump Height
2.28m
Max Hinge Pin Height
3.18m
Max Reach At Full Height
1.30m
Reach At Ground Level
1.10m
Bucket Capacity
0.43m³
Loader Arm Breakout Force
2968kgf
Dump Angle
42°
Engine Brand
Kohler
Engine Model
KDI 1 903 TCR
Engine Power
42HP
Max Torque
225Nm
Rated Speed
2600 rpm
Fuel Tank Capacity
84L
Emission Standard
103.3
Transmission Type
-
Max Travel Speed
12.5km/h
Operating Weight
5.038Ton
Rated Operating Capacity
1957kg
Rated Operating Capacity (optional)
-
Max Tipping Load
3889kg
Lift Path
-
Overall Length
3.80m
Overall Width
1.90m
Overall Height
2.08m
Wheelbase
2.10m
Ground Clearance
230mm
Turning Radius
2.30m

Manitou 1050RT Skid Steer Loader
Hydraulic Flow Rate
55L/min
Hydraulic Pressure
-
Hydraulic System Capacity
30L
Max Dump Height
2.134m
Max Hinge Pin Height
2.769m
Max Reach At Full Height
-
Reach At Ground Level
-
Bucket Capacity
-
Loader Arm Breakout Force
-
Dump Angle
38°
Engine Brand
Yanmar
Engine Model
3TNV88C-KMSV
Engine Power
34.20HP
Max Torque
109.40Nm
Rated Speed
2800rpm
Fuel Tank Capacity
36L
Emission Standard
-
Transmission Type
-
Max Travel Speed
10.10km/h
Operating Weight
2.14Ton
Rated Operating Capacity
-
Rated Operating Capacity (optional)
-
Max Tipping Load
1361kg
Lift Path
-
Overall Length
2.985m
Overall Width
1.290m
Overall Height
1.816m
Wheelbase
1.283m
Ground Clearance
0.191mm
Turning Radius
-

ACE SS 75 Skid Steer Loader
Hydraulic Flow Rate
82L/min
Hydraulic Pressure
-
Hydraulic System Capacity
65L
Max Dump Height
2.29m
Max Hinge Pin Height
3.15m
Max Reach At Full Height
0.68m
Reach At Ground Level
-
Bucket Capacity
0.4m³
Loader Arm Breakout Force
-
Dump Angle
40°
Engine Brand
ACE / Simpson
Engine Model
A50 / TSJ436
Engine Power
50 / 60 / 75HP
Max Torque
-
Rated Speed
2100 / 2200rpm
Fuel Tank Capacity
55L
Emission Standard
Bharat (TREM) Stage III A / CEV / BSIII / Tier 2 / BS-III
Transmission Type
Infinitely variable hydrostatic drive
Max Travel Speed
10km/h
Operating Weight
2.85Ton
Rated Operating Capacity
750kg
Rated Operating Capacity (optional)
-
Max Tipping Load
1500kg
Lift Path
-
Overall Length
3.62m
Overall Width
1.645m
Overall Height
2.11m
Wheelbase
1.01m
Ground Clearance
185mm
Turning Radius
-

Gamzen 5050 Skid Steer Loader
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Hydraulic System Capacity
-
Max Dump Height
2.236m
Max Hinge Pin Height
2.87m
Max Reach At Full Height
0.686m
Reach At Ground Level
-
Bucket Capacity
0.5m³
Loader Arm Breakout Force
-
Dump Angle
42°
Engine Brand
Hyundai/Cummins
Engine Model
-
Engine Power
-
Max Torque
-
Rated Speed
-
Fuel Tank Capacity
-
Emission Standard
-
Transmission Type
-
Max Travel Speed
11.0km/h
Operating Weight
2.88Ton
Rated Operating Capacity
850kg
Rated Operating Capacity (optional)
-
Max Tipping Load
1680kg
Lift Path
-
Overall Length
3.27m
Overall Width
1.69m
Overall Height
2.025m
Wheelbase
1.045m
Ground Clearance
203mm
Turning Radius
1.858m

Gamzen 8080 EX Skid Steer Loader
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Hydraulic System Capacity
-
Max Dump Height
3.532m
Max Hinge Pin Height
-
Max Reach At Full Height
1.021m
Reach At Ground Level
-
Bucket Capacity
0.7m³
Loader Arm Breakout Force
-
Dump Angle
38°
Engine Brand
Cummins
Engine Model
-
Engine Power
-
Max Torque
-
Rated Speed
-
Fuel Tank Capacity
-
Emission Standard
-
Transmission Type
-
Max Travel Speed
-
Operating Weight
3.659674Ton
Rated Operating Capacity
1140kg
Rated Operating Capacity (optional)
-
Max Tipping Load
2280kg
Lift Path
-
Overall Length
3509m
Overall Width
1.886m
Overall Height
2.055m
Wheelbase
1.181m
Ground Clearance
195mm
Turning Radius
-
