Dingli JCPT3214DC Scissor Lift Specifications

dingli

The Dingli JCPT3214DC Scissor Lift is a high-capacity, zero-emission access platform engineered for rough terrain and outdoor industrial applications. With a 750kg load capacity and the ability to drive at full height, it offers superior performance for construction, maintenance, and large-scale installation projects. Its 1.40m wide chassis ensures enhanced passability in challenging environments, while 4-wheel drive and steering deliver excellent maneuverability. The automatic self-levelling system guarantees stability on uneven surfaces, enhancing safety and operator confidence. Powered by a robust 80V/520Ah high-capacity battery pack, the JCPT3214DC runs cleanly and quietly, making it an ideal choice for eco-conscious job sites. Whether you're working on building façades, utility installations, or outdoor infrastructure, this scissor lift combines power, precision, and environmental performance in one rugged machine.

Dingli JCPT3214DC Scissor Lift Specifications

ENGINE / BATTERY SYSTEM

Battery Type
Lithium
Battery Voltage / Capacity
80V / 520Ah
Charger Input Voltage
80V
Charger Output / Type
80A

TRANSMISSION & PERFORMANCE

Drive Type
4×4
Gradeability
30%
Lift Time (Loaded)
160sec
Lower Time (Loaded)
105sec
Max Travel Speed (Stowed)
1.5km/h
Travel Speed (Raised)
0.1km/h

OPERATING WEIGHT & LOAD CAPACITY

Extension Deck Capacity
750kg
Max Platform Capacity
750kg
Max Platform Occupants (In/Out)
2/2persons
Operating Weight
22.2Ton

DIMENSIONS

Ground Clearance (Stowed)
0.19m
Overall Height (Rails Lowered)
3.17m
Overall Height (Rails Raised)
4.16m
Overall Length (Stowed)
6.41m
Overall Width
1.40m
Wheelbase
4.87m

HYDRAULIC SYSTEM

Hydraulic Oil Capacity
220L

PLATFORM & REACH PERFORMANCE

Max Platform Height
30.00m
Max Working Height
32.00m
Platform Extension Length
1.90m
Platform Size (L×W)
5.85m×1.20mm

SAFETY & FEATURES

Max Side Slope (Lateral)
Max Slope (Fore/Aft)
Platform Control System
Proportional Joystick Controls
Tilt Sensor
Yes
Tires
28×12-22

BRAKE SYSTEM

Service Brake Type
Automatic Braking System

STEERING & TURNING

Steering Type
Four-Wheel Steering
Turning Radius (Inside)
2.60m
Turning Radius (Outside)
3.50m
