Dingli JCPT1812DCL Scissor Lift Specifications

dingli

The Dingli JCPT1812DCL Scissor Lift is a rugged, zero-emission aerial platform designed for construction, maintenance, and industrial applications in rough terrain environments. With a load capacity of 680kg and the ability to drive at full height, it delivers reliable performance for high-reach and heavy-duty tasks. Its compact 1.25m width ensures easy maneuverability in tight or confined workspaces. The lift features a one-key two-way extension deck that can be stopped at any point, offering exceptional platform flexibility. Equipped with automatic self-levelling, 4-wheel drive and steering, and a powerful 48V/450Ah battery pack, it provides excellent stability, control, and long operational runtime. Operating with no noise and zero emissions, the JCPT1812DCL is the perfect choice for eco-conscious job sites demanding efficiency, durability, and all-terrain capability.

Dingli JCPT1812DCL Scissor Lift Specifications

ENGINE / BATTERY SYSTEM

Battery Voltage / Capacity
48V / 360Ah
Charger Output / Type
48V / 60

OPERATING WEIGHT & LOAD CAPACITY

Extension Deck Capacity
500 kg
Max Platform Capacity
500 kg
Max Platform Occupants (In/Out)
2 persons
Operating Weight
7.140 Ton

TRANSMISSION & PERFORMANCE

Gradeability
30 %
Lift Time (Loaded)
70sec
Lower Time (Loaded)
76sec
Max Travel Speed (Stowed)
4.5km/h
Travel Speed (Raised)
0.4 km/h

DIMENSIONS

Ground Clearance (Stowed)
0.15m
Overall Height (Rails Lowered)
2.47m
Overall Height (Rails Raised)
3.24m
Overall Length (Stowed)
3.76m
Overall Width
1.25m
Wheelbase
2.89m

HYDRAULIC SYSTEM

Hydraulic Oil Capacity
50L

PLATFORM & REACH PERFORMANCE

Max Platform Height
17.00 m
Max Working Height
19.00m
Platform Extension Length
1.20m
Platform Size (L×W)
3.44 × 1.17 m

SAFETY & FEATURES

Max Side Slope (Lateral)
1.5°
Max Slope (Fore/Aft)
Tires
22×9×16

STEERING & TURNING

Turning Radius (Inside)
1.00 m
Turning Radius (Outside)
3.50m
