Bull HD76 Wheel Loader
Bull Machines Private Limited
Tamil Nadu
The Bull HD76 Wheel Loader is a high-performance machine engineered for demanding material handling applications across construction, quarrying, agriculture, and mining sectors. Powered by a robust 76 HP Kirloskar engine and equipped with a 1.1 cu.m GP shovel, it delivers superior breakout force of 8183 kgf and a payload capacity of 1800 kg. With a maximum dump height of 2.93 meters and a hinge pin height of 3.61 meters, the Bull HD76 ensures faster loading cycles and enhanced productivity. Its advanced Carraro synchroshuttle transmission and optional hydrostatic drive provide seamless operation and exceptional maneuverability. Built with SMART hydraulic technology at 230 bar pressure and a heavy-duty chassis, the Bull HD76 Wheel Loader is designed to perform reliably in the toughest working conditions, offering unbeatable strength, durability, and operator comfort.
Bull HD76 Wheel Loader
Bull Machines Private Limited
Tamil Nadu
The Bull HD76 Wheel Loader is a high-performance machine engineered for demanding material handling applications across construction, quarrying, agriculture, and mining sectors. Powered by a robust 76 HP Kirloskar engine and equipped with a 1.1 cu.m GP shovel, it delivers superior breakout force of 8183 kgf and a payload capacity of 1800 kg. With a maximum dump height of 2.93 meters and a hinge pin height of 3.61 meters, the Bull HD76 ensures faster loading cycles and enhanced productivity. Its advanced Carraro synchroshuttle transmission and optional hydrostatic drive provide seamless operation and exceptional maneuverability. Built with SMART hydraulic technology at 230 bar pressure and a heavy-duty chassis, the Bull HD76 Wheel Loader is designed to perform reliably in the toughest working conditions, offering unbeatable strength, durability, and operator comfort.
Product Description
The Bull HD76 Wheel Loader is a high-performance machine engineered for demanding material handling ...
View the full brochure
Bull HD76 Wheel Loader Comparison with Similar Wheel Loader
Bull HD76 Wheel Loader
Fuel Tank Capacity
115L
Emission Standard
EURO-III A
Transmission Type
Synchroshuttle (Carraro)
Max Travel Speed
41km/h
Operating Weight
7.85Ton
Rated Operating Capacity
-
Engine Brand
Kirloskar
Engine Model
4R 1040, TC EURO-III A
Engine Power
76HP
Max Torque
300 Nm
Rated Speed
2200rpm
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic Flow Rate
113L/min
Hydraulic Pressure
230Bar
Hydraulic System Capacity
120L
Max Dump Height
2.93m
Max Hinge Pin Height
3.61m
Max Reach At Full Height
1.42m
Reach At Ground Level
1.60m
Bucket Capacity
1.1m³
Loader Arm Breakout Force
5251kgf
Dump Angle
45°
Lift Path
-
Overall Length
6.04m
Overall Width
2.35m
Overall Height
3.71m
Wheelbase
2.22m
Ground Clearance
480mm
Turning Radius
8.8m
Displacement
-
Hydraulic Oil Capacity
-
Number Of Gears (f/r)
-
Max Travel Speed (f)
-
Max Travel Speed (r)
-
Service Brake Type
-
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Parking Brake Type
-
Steering Type
-
Steering Angle
-
Oscillation Angle
-
Max Load Over Height
-
Loader Bucket Capacity
-
Front Axle Oscillation
-
Battery Voltage
-
Standard Tires (front/rear)
-
Liugong 856HE Max Electric Wheel Loader
Fuel Tank Capacity
Electric – not applicableL
Emission Standard
-
Transmission Type
Planetary, power shift
Max Travel Speed
-
Operating Weight
21000kg
Rated Operating Capacity
-
Engine Brand
CATL
Engine Model
LFP
Engine Power
160kW
Max Torque
-
Rated Speed
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic Flow Rate
100L/min
Hydraulic Pressure
250Bar
Hydraulic System Capacity
-
Max Dump Height
3.77m
Max Hinge Pin Height
-
Max Reach At Full Height
1.05m
Reach At Ground Level
-
Bucket Capacity
-
Loader Arm Breakout Force
137kN
Dump Angle
-
Lift Path
-
Overall Length
6.3m
Overall Width
2.25m
Overall Height
3.25m
Wheelbase
-
Ground Clearance
350mm
Turning Radius
4.966m
Displacement
-
Hydraulic Oil Capacity
100L
Number Of Gears (f/r)
2/1
Max Travel Speed (f)
40km/h
Max Travel Speed (r)
13km/h
Service Brake Type
Fully Hydraulic
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Parking Brake Type
Hydraulic Wet Brake + Manual Handle Control
Steering Type
Articulated
Steering Angle
-
Oscillation Angle
±8°
Max Load Over Height
3.55m
Loader Bucket Capacity
2.7–5.6m³
Front Axle Oscillation
±8°
Battery Voltage
618V
Standard Tires (front/rear)
16/70-20 PR14/TT L-3
liugong 818h wheel loader
Fuel Tank Capacity
88L
Emission Standard
-
Transmission Type
Countershaft Powershift, 3 Element Single Stage
Max Travel Speed
-
Operating Weight
6400kg
Rated Operating Capacity
-
Engine Brand
Kirloskar
Engine Model
4R1040T-I (T)
Engine Power
54.8kW
Max Torque
400Nm
Rated Speed
2200rpm
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic Flow Rate
-
Hydraulic Pressure
148Bar
Hydraulic System Capacity
-
Max Dump Height
2.68m
Max Hinge Pin Height
-
Max Reach At Full Height
0.92m
Reach At Ground Level
-
Bucket Capacity
-
Loader Arm Breakout Force
45kN
Dump Angle
-
Lift Path
-
Overall Length
5.96m
Overall Width
2.02m
Overall Height
2.96m
Wheelbase
-
Ground Clearance
285mm
Turning Radius
R1:5.28 R2:4.63 m
Displacement
4.76L
Hydraulic Oil Capacity
65L
Number Of Gears (f/r)
Forward 2 / Reverse 1
Max Travel Speed (f)
8/25km/h
Max Travel Speed (r)
8/25km/h
Service Brake Type
Air Over Hydraulic Caliper Disc Brake
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Parking Brake Type
Mechanical Actuation
Steering Type
Articulated Hydrostatic Steering
Steering Angle
± 35°°
Oscillation Angle
± 10°°
Max Load Over Height
2.94m
Loader Bucket Capacity
1.2m³
Front Axle Oscillation
± 10°°
Battery Voltage
12V
Standard Tires (front/rear)
16/70-20 PR14
Liugong 838T MAX WHEEL LOADER
Fuel Tank Capacity
180L
Emission Standard
-
Transmission Type
Powershift
Max Travel Speed
-
Operating Weight
12324kg
Rated Operating Capacity
-
Engine Brand
Ashok Leyland
Engine Model
H6C516022
Engine Power
118kW
Max Torque
650Nm
Rated Speed
2200rpm
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic Flow Rate
-
Hydraulic Pressure
210Bar
Hydraulic System Capacity
-
Max Dump Height
2.95m
Max Hinge Pin Height
-
Max Reach At Full Height
1.15m
Reach At Ground Level
-
Bucket Capacity
-
Loader Arm Breakout Force
102kN
Dump Angle
-
Lift Path
-
Overall Length
7.41m
Overall Width
2.46m
Overall Height
3.32m
Wheelbase
-
Ground Clearance
380mm
Turning Radius
5.05m
Displacement
-
Hydraulic Oil Capacity
104L
Number Of Gears (f/r)
2 / 1
Max Travel Speed (f)
17/40km/h
Max Travel Speed (r)
17km/h
Service Brake Type
Air Over Hydraulic Drum Brake
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Parking Brake Type
Mechanical Actuation
Steering Type
Articulated
Steering Angle
38°
Oscillation Angle
11°
Max Load Over Height
3.39m
Loader Bucket Capacity
2.4m³
Front Axle Oscillation
11°
Battery Voltage
24V
Standard Tires (front/rear)
17.5–25 PR16
LIUGONG 838TE WHEEL LOADERS
Fuel Tank Capacity
-
Emission Standard
-
Transmission Type
Planetary electronic control shift
Max Travel Speed
-
Operating Weight
-
Rated Operating Capacity
-
Engine Brand
Electric (Battery Powered)
Engine Model
-
Engine Power
Peak Power Drive Motor: 120 kW Peak Power Hydraulic Motor: 95 kWkW
Max Torque
-
Rated Speed
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic Flow Rate
13625L/min
Hydraulic Pressure
210Bar
Hydraulic System Capacity
-
Max Dump Height
2.95m
Max Hinge Pin Height
-
Max Reach At Full Height
1.14m
Reach At Ground Level
-
Bucket Capacity
-
Loader Arm Breakout Force
125kN
Dump Angle
-
Lift Path
-
Overall Length
7.50m
Overall Width
3.2m
Overall Height
3.2m
Wheelbase
-
Ground Clearance
328mm
Turning Radius
Bucket Carry: 6218 mm (6.21 m) Outside of Tire: 5840 mm (5.84 m)m
Displacement
-
Hydraulic Oil Capacity
130L
Number Of Gears (f/r)
2/1
Max Travel Speed (f)
40km/h
Max Travel Speed (r)
15km/h
Service Brake Type
Full hydraulic
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Parking Brake Type
Drum
Steering Type
Large displacement steering
Steering Angle
38°
Oscillation Angle
10°
Max Load Over Height
3.85m
Loader Bucket Capacity
2.4m³
Front Axle Oscillation
10°
Battery Voltage
DC 624 VV
Standard Tires (front/rear)
17.5–25 PR16 L-3 TT
