Aquarius 37 ZX Truck Mounted Boom Pumps

Aquarius Engineers Private Limited

Gujarat

The Aquarius 37 ZX Truck Mounted Boom Pump is designed for large-scale construction projects that demand high efficiency and precision. It features a powerful 82 kW slave engine and a “Z” fold boom for compact deployment, offering up to 31.82 meters of horizontal reach and 36.75 meters of vertical reach, ideal for high-rise buildings and large infrastructure projects. The pump’s reach depth of 23.7 meters and hydraulic transmission ratio of 1:6.5/1:4.37 ensure optimal performance on complex job sites. With a maximum theoretical concrete output of 85 m³/hr, it is capable of handling large volumes quickly and effectively. The pump also boasts a robust 360-degree slewing range, easy clean hopper with 600-liter capacity, and a 205-liter water tank, ensuring smooth and uninterrupted operations, making it an ideal solution for demanding construction applications.

Product Description

The Aquarius 37 ZX Truck Mounted Boom Pump is designed for large-scale construction projects that de...

View the full brochure

Aquarius 37 ZX Truck Mounted Boom Pumps Comparison with Similar Concrete Boom Pump

Aquarius 37 ZX Truck Mounted Boom Pumps

Aquarius 37 ZX Truck Mounted Boom Pumps

Get Latest Price
Rating
4.4

Engine Power

109.96HP

Hydraulic System Pressure

360Bar

Max Concrete Pressure

80Bar

Max Pumping Output

85m³/h

No. Of Strokes (max.)

25min⁻¹

Horizontal Reach

31.82m

Vertical Reach

36.75m

Slewing Range

365°

End Hose Length

4m

Chassis Allowable Gvw

28000kg

Hydraulic Flow Rate

-

Hydraulic Pressure

360Bar

Hopper Capacity

600L

Concrete Output Max

85m³/h

Number Of Articulations

4

Number Of Folds (max.)

4

Currently Viewing
AJAX A44 RZX Boom Pump

AJAX A44 RZX Boom Pump

Get Latest Price
Rating
4.4

Engine Power

-

Hydraulic System Pressure

365Bar

Max Concrete Pressure

83Bar

Max Pumping Output

90m³/h

No. Of Strokes (max.)

26min⁻¹

Horizontal Reach

38.5m

Vertical Reach

43.1m

Slewing Range

365°

End Hose Length

3m

Chassis Allowable Gvw

-

Hydraulic Flow Rate

-

Hydraulic Pressure

365Bar

Hopper Capacity

600L

Concrete Output Max

90m³/h

Number Of Articulations

5

Number Of Folds (max.)

5

Aquarius M 20.07 Z Truck Mounted Boom Pumps

Aquarius M 20.07 Z Truck Mounted Boom Pumps

Get Latest Price
Rating
4.4

Engine Power

109.96HP

Hydraulic System Pressure

300Bar

Max Concrete Pressure

71Bar

Max Pumping Output

65m³/h

No. Of Strokes (max.)

25min⁻¹

Horizontal Reach

16.4m

Vertical Reach

20m

Slewing Range

365°

End Hose Length

3m

Chassis Allowable Gvw

16000kg

Hydraulic Flow Rate

-

Hydraulic Pressure

300Bar

Hopper Capacity

600L

Concrete Output Max

65m³/h

Number Of Articulations

3

Number Of Folds (max.)

3

Zoomlion 43X-5RZ Concrete Pump Truck

Zoomlion 43X-5RZ Concrete Pump Truck

Get Latest Price
Rating
4.4

Engine Power

402.31HP

Hydraulic System Pressure

110Bar

Max Concrete Pressure

110Bar

Max Pumping Output

140m³/h

No. Of Strokes (max.)

-

Horizontal Reach

39m

Vertical Reach

43m

Slewing Range

-

End Hose Length

-

Chassis Allowable Gvw

-

Hydraulic Flow Rate

-

Hydraulic Pressure

-

Hopper Capacity

-

Concrete Output Max

140m³/h

Number Of Articulations

5

Number Of Folds (max.)

5

Putzmeister BSF 36-4 Truck-mounted Boom Pump

Putzmeister BSF 36-4 Truck-mounted Boom Pump

Get Latest Price
Rating
4.4

Engine Power

-

Hydraulic System Pressure

-

Max Concrete Pressure

-

Max Pumping Output

-

No. Of Strokes (max.)

-

Horizontal Reach

-

Vertical Reach

-

Slewing Range

-

End Hose Length

-

Chassis Allowable Gvw

-

Hydraulic Flow Rate

-

Hydraulic Pressure

-

Hopper Capacity

-

Concrete Output Max

-

Number Of Articulations

-

Number Of Folds (max.)

-

Compare Concrete Boom Pump

Aquarius 37 ZX Truck Mounted Boom Pumps

Aquarius 37 ZX Truck Mounted Boom Pumps

AJAX A44 RZX Boom Pump

AJAX A44 RZX Boom Pump

Add any equipment
to compare

Product

Get instant quotation on whatsapp

Connect with "Aquarius Engineers Private Limited"

Connect with Seller Instantly

About Company

Company Name

Aquarius Engineers Private Limited

GST Number

27AACCA2748L1ZI

Since

January 1981

Address

Aquarius House, Sheelavihar Colony, Off Karve Road, Pune-411038, Maharashtra, India

Aquarius Engineers Private Limited was founded in 1981, initially as a sales and service organization representing global leaders in construction equipment. Since then, it has evolved into a multifaceted manufacturing conglomerate with prestigious joint ventures and state-of-the-art manufacturing plants in Pune and Goa. With offices across India and exports to neighboring countries, Aquarius Engineers is committed to bringing cutting-edge technology to the construction industry. The company’s focus on quality and innovation has positioned it as a key player in the market.
