Aquarius 37 ZX Truck Mounted Boom Pumps
Aquarius Engineers Private Limited
Gujarat
The Aquarius 37 ZX Truck Mounted Boom Pump is designed for large-scale construction projects that demand high efficiency and precision. It features a powerful 82 kW slave engine and a “Z” fold boom for compact deployment, offering up to 31.82 meters of horizontal reach and 36.75 meters of vertical reach, ideal for high-rise buildings and large infrastructure projects. The pump’s reach depth of 23.7 meters and hydraulic transmission ratio of 1:6.5/1:4.37 ensure optimal performance on complex job sites. With a maximum theoretical concrete output of 85 m³/hr, it is capable of handling large volumes quickly and effectively. The pump also boasts a robust 360-degree slewing range, easy clean hopper with 600-liter capacity, and a 205-liter water tank, ensuring smooth and uninterrupted operations, making it an ideal solution for demanding construction applications.
Aquarius 37 ZX Truck Mounted Boom Pumps
Aquarius Engineers Private Limited
Gujarat
The Aquarius 37 ZX Truck Mounted Boom Pump is designed for large-scale construction projects that demand high efficiency and precision. It features a powerful 82 kW slave engine and a “Z” fold boom for compact deployment, offering up to 31.82 meters of horizontal reach and 36.75 meters of vertical reach, ideal for high-rise buildings and large infrastructure projects. The pump’s reach depth of 23.7 meters and hydraulic transmission ratio of 1:6.5/1:4.37 ensure optimal performance on complex job sites. With a maximum theoretical concrete output of 85 m³/hr, it is capable of handling large volumes quickly and effectively. The pump also boasts a robust 360-degree slewing range, easy clean hopper with 600-liter capacity, and a 205-liter water tank, ensuring smooth and uninterrupted operations, making it an ideal solution for demanding construction applications.
Product Description
The Aquarius 37 ZX Truck Mounted Boom Pump is designed for large-scale construction projects that de...
View the full brochure
Aquarius 37 ZX Truck Mounted Boom Pumps Comparison with Similar Concrete Boom Pump

Aquarius 37 ZX Truck Mounted Boom Pumps
Engine Power
109.96HP
Hydraulic System Pressure
360Bar
Max Concrete Pressure
80Bar
Max Pumping Output
85m³/h
No. Of Strokes (max.)
25min⁻¹
Horizontal Reach
31.82m
Vertical Reach
36.75m
Slewing Range
365°
End Hose Length
4m
Chassis Allowable Gvw
28000kg
Hydraulic Flow Rate
-
Hydraulic Pressure
360Bar
Hopper Capacity
600L
Concrete Output Max
85m³/h
Number Of Articulations
4
Number Of Folds (max.)
4

AJAX A44 RZX Boom Pump
Engine Power
-
Hydraulic System Pressure
365Bar
Max Concrete Pressure
83Bar
Max Pumping Output
90m³/h
No. Of Strokes (max.)
26min⁻¹
Horizontal Reach
38.5m
Vertical Reach
43.1m
Slewing Range
365°
End Hose Length
3m
Chassis Allowable Gvw
-
Hydraulic Flow Rate
-
Hydraulic Pressure
365Bar
Hopper Capacity
600L
Concrete Output Max
90m³/h
Number Of Articulations
5
Number Of Folds (max.)
5

Aquarius M 20.07 Z Truck Mounted Boom Pumps
Engine Power
109.96HP
Hydraulic System Pressure
300Bar
Max Concrete Pressure
71Bar
Max Pumping Output
65m³/h
No. Of Strokes (max.)
25min⁻¹
Horizontal Reach
16.4m
Vertical Reach
20m
Slewing Range
365°
End Hose Length
3m
Chassis Allowable Gvw
16000kg
Hydraulic Flow Rate
-
Hydraulic Pressure
300Bar
Hopper Capacity
600L
Concrete Output Max
65m³/h
Number Of Articulations
3
Number Of Folds (max.)
3

Zoomlion 43X-5RZ Concrete Pump Truck
Engine Power
402.31HP
Hydraulic System Pressure
110Bar
Max Concrete Pressure
110Bar
Max Pumping Output
140m³/h
No. Of Strokes (max.)
-
Horizontal Reach
39m
Vertical Reach
43m
Slewing Range
-
End Hose Length
-
Chassis Allowable Gvw
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Hopper Capacity
-
Concrete Output Max
140m³/h
Number Of Articulations
5
Number Of Folds (max.)
5

Putzmeister BSF 36-4 Truck-mounted Boom Pump
Engine Power
-
Hydraulic System Pressure
-
Max Concrete Pressure
-
Max Pumping Output
-
No. Of Strokes (max.)
-
Horizontal Reach
-
Vertical Reach
-
Slewing Range
-
End Hose Length
-
Chassis Allowable Gvw
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Hopper Capacity
-
Concrete Output Max
-
Number Of Articulations
-
Number Of Folds (max.)
-
Compare Concrete Boom Pump

Aquarius 37 ZX Truck Mounted Boom Pumps

AJAX A44 RZX Boom Pump
Add any equipment
to compare

Get instant quotation on whatsapp
Connect with "Aquarius Engineers Private Limited"
Connect with Seller Instantly
About Company
Company Name
Aquarius Engineers Private Limited
GST Number
27AACCA2748L1ZI
Since
January 1981
Address
Aquarius House, Sheelavihar Colony, Off Karve Road, Pune-411038, Maharashtra, India
Aquarius Engineers Private Limited was founded in 1981, initially as a sales and service organization representing global leaders in construction equipment. Since then, it has evolved into a multifaceted manufacturing conglomerate with prestigious joint ventures and state-of-the-art manufacturing plants in Pune and Goa. With offices across India and exports to neighboring countries, Aquarius Engineers is committed to bringing cutting-edge technology to the construction industry. The company’s focus on quality and innovation has positioned it as a key player in the market.
