ACE SA 150 Piling Rig
Action Construction Equipment Limited
Haryana
The ACE SA 150 Piling Rigs are designed for high performance and durability in hard soil conditions. These rigs provide a comprehensive solution for various underground foundation needs, including static pile drivers, dual-purpose drilling rigs, hydraulic crawler drills, and tunnel boring machines. Ideal for urban infrastructure, metro and rapid rail projects, and bridge and flyover construction, they offer versatility with a piling diameter range of 500mm to 3500mm and a maximum depth of 135m. The rigs feature a torque range from 150 kN.m to 600 kN.m, ensuring effective handling of challenging ground conditions. Their rugged design and advanced capabilities make them essential for delivering stable, reliable foundations across diverse construction segments.
ACE SA 150 Piling Rig
Action Construction Equipment Limited
Haryana
The ACE SA 150 Piling Rigs are designed for high performance and durability in hard soil conditions. These rigs provide a comprehensive solution for various underground foundation needs, including static pile drivers, dual-purpose drilling rigs, hydraulic crawler drills, and tunnel boring machines. Ideal for urban infrastructure, metro and rapid rail projects, and bridge and flyover construction, they offer versatility with a piling diameter range of 500mm to 3500mm and a maximum depth of 135m. The rigs feature a torque range from 150 kN.m to 600 kN.m, ensuring effective handling of challenging ground conditions. Their rugged design and advanced capabilities make them essential for delivering stable, reliable foundations across diverse construction segments.
Product Description
The ACE SA 150 Piling Rigs are designed for high performance and durability in hard soil conditions....
View the full brochure
ACE SA 150 Piling Rig Comparison with Similar Piling Rig
ACE SA 150 Piling Rig
Engine Brand
CUMMINS
Engine Model
QSB7-C166G3
Engine Power
124kW
Rated Speed
2050rpm
Emission Standard
-
Engine Displacement
-
Max Output Torque
150kN·m
Rotation Speed Range
40rpm
High Speed Throwing Soil
70rpm
Max. Drilling Diameter
1300mm
Max. Drilling Depth (interlocking Kelly)
35m
Max. Drilling Depth (friction Kelly)
46m
Crowd Force (push)
150kN
Crowd Force (pull)
150kN
Stroke Length
4000mm
Max. Lifting Capacity
50kN
Max. Line Speed
45m/min
Wire Rope Diameter
-
Forward Tilt
5°
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
600mm
Chassis Length
4450mm
Crawler Extension Width
3500mm
Swing Radius
-
Overall Height
16.3mm
Transport Height
-
Transport Width
-
Operating Weight
40.5Ton
Max. Traction Force
-
Max. Travel Speed
3km/h
Max. Gradeability
15°
Friction Kelly Bar
46000mm
Interlocking Kelly Bar
35000mm
Mait India THH6 Rotary Drilling Piling Rig
Engine Brand
-
Engine Model
-
Engine Power
-
Rated Speed
-
Emission Standard
-
Engine Displacement
-
Max Output Torque
-
Rotation Speed Range
-
High Speed Throwing Soil
-
Max. Drilling Diameter
-
Max. Drilling Depth (interlocking Kelly)
-
Max. Drilling Depth (friction Kelly)
-
Crowd Force (push)
-
Crowd Force (pull)
-
Stroke Length
-
Max. Lifting Capacity
-
Max. Line Speed
-
Wire Rope Diameter
-
Forward Tilt
-
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
-
Chassis Length
-
Crawler Extension Width
-
Swing Radius
-
Overall Height
-
Transport Height
-
Transport Width
-
Operating Weight
-
Max. Traction Force
-
Max. Travel Speed
-
Max. Gradeability
-
Friction Kelly Bar
-
Interlocking Kelly Bar
-
Mait India MDT-60B Rotary Drilling Piling Rig
Engine Brand
-
Engine Model
-
Engine Power
-
Rated Speed
-
Emission Standard
-
Engine Displacement
-
Max Output Torque
-
Rotation Speed Range
-
High Speed Throwing Soil
-
Max. Drilling Diameter
-
Max. Drilling Depth (interlocking Kelly)
-
Max. Drilling Depth (friction Kelly)
-
Crowd Force (push)
-
Crowd Force (pull)
-
Stroke Length
-
Max. Lifting Capacity
-
Max. Line Speed
-
Wire Rope Diameter
-
Forward Tilt
-
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
-
Chassis Length
-
Crawler Extension Width
-
Swing Radius
-
Overall Height
-
Transport Height
-
Transport Width
-
Operating Weight
-
Max. Traction Force
-
Max. Travel Speed
-
Max. Gradeability
-
Friction Kelly Bar
-
Interlocking Kelly Bar
-
Mait India MDT-180B Rotary Drilling Piling Rig
Engine Brand
-
Engine Model
-
Engine Power
-
Rated Speed
-
Emission Standard
-
Engine Displacement
-
Max Output Torque
-
Rotation Speed Range
-
High Speed Throwing Soil
-
Max. Drilling Diameter
-
Max. Drilling Depth (interlocking Kelly)
-
Max. Drilling Depth (friction Kelly)
-
Crowd Force (push)
-
Crowd Force (pull)
-
Stroke Length
-
Max. Lifting Capacity
-
Max. Line Speed
-
Wire Rope Diameter
-
Forward Tilt
-
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
-
Chassis Length
-
Crawler Extension Width
-
Swing Radius
-
Overall Height
-
Transport Height
-
Transport Width
-
Operating Weight
-
Max. Traction Force
-
Max. Travel Speed
-
Max. Gradeability
-
Friction Kelly Bar
-
Interlocking Kelly Bar
-
XCMG XR80I Rotary Drilling Piling Rig
Engine Brand
Cummins
Engine Model
-
Engine Power
103kW
Rated Speed
-
Emission Standard
-
Engine Displacement
-
Max Output Torque
106 kN·m
Rotation Speed Range
-
High Speed Throwing Soil
-
Max. Drilling Diameter
1200 mm
Max. Drilling Depth (interlocking Kelly)
25m
Max. Drilling Depth (friction Kelly)
-
Crowd Force (push)
-
Crowd Force (pull)
-
Stroke Length
2.5mm
Max. Lifting Capacity
-
Max. Line Speed
-
Wire Rope Diameter
-
Forward Tilt
-
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
-
Chassis Length
-
Crawler Extension Width
-
Swing Radius
-
Overall Height
-
Transport Height
-
Transport Width
-
Operating Weight
-
Max. Traction Force
-
Max. Travel Speed
-
Max. Gradeability
-
Friction Kelly Bar
-
Interlocking Kelly Bar
-
